Motherboard MSI MPG Z590 GAMING FORCE, Chipset Z590, Supports: Intel 11th and 10th Generation. Socket 1200, Memory DDR4 5333(OC)/3200/2133 MHz, 128GB Max, Integrated: HD Audio, Network, USB 3.0. SATA 6Gb/s, M.2, ATX, Pts: 3xPCIEx16, 2xPCIEx1.
Specifications
| General specifications |
| Brand |
MSI |
| Model |
MPG Z590 GAMING FORCE |
| Color |
Negro |
| – Processor |
| For Processors |
Intel |
| CPU Socket |
Socket 1200 |
| Compatible Processors |
Supports 10th Gen Intel Core, 11th Gen Intel Core, Pentium Gold and Celeron Processors. |
| – Chipset |
| Type of use |
High performance |
| Model |
Intel Z590 |
| – Memory |
| Supported Memory Type |
DDR4 |
| Memory slots |
4 |
| Compatible Memory |
5333 (OC) / 5200 (OC) / 5000 (OC) / 4000 (OC) / 3866 (OC) / 3733 (OC) / 2400 (JEDEC) / 2133 (JEDEC) MHz |
| Maximum Memory Supported |
128 gb |
| Memory Architecture |
Dual Channel |
| – Expansion Slots |
| PCI Express x16 |
3 |
| PCI Express x1 |
2 |
| PCI Express 3.0 x1 |
2 |
| – Storage devices |
| SATA 6Gb / s |
6 |
| SATA RAID |
0, 1, 10 |
| M.2 |
3 |
| – Integrated Audio Chipset |
| Integrated Audio |
Realtek® ALC4080 Codec |
| Audio Channels |
7.1 |
| – Integrated Network |
| Chipset de Red |
Intel I225V 2.5Gbps LAN controller |
| Maximum Network Speed |
10/100/1000Mbps |
| – Rear I/O Ports |
| USB 1.1/2.0 |
4 |
| USB 3.0 |
2 |
| USB 3.1 Type-A |
3 |
| USB Type-C |
1 |
| HDMI |
1 |
| Display port |
1 |
| Network Connectors (RJ45) |
1 |
| Audio Optical |
1 |
| Audio Ports |
5 x 3.5 mm |
| – Internal I / O connector |
| USB |
2x USB 2.0, 1x USB 3.1, 1x USB 3.0 |
| ATX de 24-pin |
1 |
| ATX 12V 8-pin |
2 |
| ATX 12V 4-pin |
1 |
| SATA Express |
6 |
| WITH |
1 |
| M.2 |
3 |
| CPU Fan |
1 |
| TPM |
1 |
| Clear CMOS button |
1 |
| – Specifications |
| form factor |
ATX |
| Physical Characteristics |
| Dimensions |
30.5 cm x 24.4 cm |
